Basic config:
Router> enable
Router# configure terminal
Router(config)# hostname R1
R1(config)# interface g0/0
R1(config-if)# ip address 192.168.1.1 255.255.255.0
R1(config-if)# no shutdown
R1(config)# line console 0
R1(config-line)# password cisco
R1(config-line)# login
R1(config)# enable secret class
R1# write memory
Wireless Router
SSID=---
Enable WPA2
Password: password
DHCP: ip address:----
Save settings
Pc/laptop
Ip config
Pc/laptop==ip address: 192.168.-----/?
Subnet mask: 255.255.255.---
Default gateway: 192.168.-----/?
Server-PT
Ip config
Set ip add:192.168.----/?
Subnet mask: 255.255.255.---
Default gateway: 192.168.-----/?
Banner
En
Conf t
Banner motd $-----$
Wireless router to laptop
Turn off the laptop.
Remove the Ethernet module.
Add a WPC300N wireless module.
Turn on the laptop.
Configure the Wireless Router
Open the Wireless Router settings.
Set the SSID (e.g., "MyWiFi").
Enable Wireless Security (e.g., WPA2 and set a password).
Configure DHCP to assign IP addresses automatically.
Save settings and restart.
Connect the Laptop to WiFi
Open the Laptop Desktop.
Go to PC Wireless.
Click Connect and select the SSID of the wireless router.
Enter the WiFi password.
The laptop should now be connected!
Connections:
Pc : copper straight-through cable
Switch: copper straight-through cable
Router: copper straight-through cable
Wireless R: copper straight-through cable
Router to Rouetr: Serial DCE/DTE cable
Switch to Switch: copper crossover cable
Console config: console cable
